Eight Position (RJ-45) Modular Cable


Internet Services


Eight Position (RJ-45) Modular Cable

T568B
(with clip down)

T568A
(with clip down)
  • UTP consists of 4 twisted pairs.  The standard colors are:
white/blue – blue
white/orange – orange
white/green – green
white/brown – brown
  • Hub to Hub or
    Computer to Computer connection:  one end T568A, other end T568B (Crossover Cable).
  • Hub to Computer connection: T568B on each end.
